Chapter 3
VX900-I USER MANUAL
34
PC Health Status
On motherboards support hardware monitoring, this item lets you monitor the
parameters for critical voltages, temperatures and fan speeds.
Help Item
CMOS Setup Utility - Copyright (C) 1985-2005, American Megatrends, Inc.
PC Health Status
-=- System Hardware Monitor -=-
Smart Fan Function
Press Enter
Shutdown Temperature Disabled
Warning Temperature Disabled
CPU Temperature : 35°C/95°F
CPU Fan Speed : 4354 RPM
System Fan Speed : 0RPM
CPU Vcore : 1.200 V
VDIMM : 1.524V
Case Open Warning Disabled
Chassis Opened No
: Move F10: Save ESC: Exit Enter : Select +/-/: Value
F9: Load Default Settings F1: General Help
Scroll to this item and press to view the following screen:
Smart Fan Function
Help Item
CMOS Setup Utility - Copyright (C) 1985-2005, American Megatrends, Inc.
Smart Fan Function
CPU SMART Fan Control Enabled
SMART Fan Mode Normal
SMART Fan start PWM value 28
SMART Fan start TEP. (°C) 32
CPU DeltaT +3
SMART Fan Slope PWM value 4PWM value/°C
CPU FAN Full Limit Temp 57°C
: Move F10: Save ESC: Exit Enter : Select +/-/: Value
F9: Load Default Settings F1: General Help
CPU SMART FAN Control (Enabled)
This item allows you to enable or disable the control of the CPU fan speed by
changing the fan voltage.
SMART Fan Mode (Normal)
This item allows you to select the fan mode (Normal, Quiet, Silent, or Manual) for
a better operation environment. If you choose Normal mode, the fan speed will be
auto adjusted depending on the CPU temperature. If you choose Quite mode, the
fan speed will be auto minimized for quiet environment. If you choose Silent mode,
the fan speed will be auto restricted to make system more quietly. If you choose
Manual mode, the fan speed will be adjust depending on users’ parameters.
SMART Fan start PWM value (28)
This item is used to set the start PWM value of the smart fan.
