Chapter 3
VX900-I USER MANUAL
31
Legacy USB Support (Enabled)
Use this item to enable or disable support for legacy USB devices.
Parallel Port IRQ (IRQ7)
Use this item to assign IRQ to the parallel port.
USB Functions (Enabled)
Use this item to enable or disable the USB function.
Integrated Peripherals
This page sets up some parameters for peripheral devices connected to the system.
CMOS Setup Utility - Copyright (C) 1985-2005, American Megatrends, Inc.
Integrated Peripherals
SATA Configuration IDE
Onboard AUDIO Function Enabled
Onboard LAN Function Enabled
Onboard LAN Boot ROM Disabled
Serial Port1 Address Enabled
Serial Port2 Address 2F8/ IRQ3
Serial Port3 Address 3E8/ IRQ4
Parallel Port Address 378
Parallel Port Mode Normal
Parallel Port IRQ IRQ7
USB Functions Enabled
Legacy USB Support Enabled
Help Item
Onboard AUDIO Function (Enabled)
Use this item to enable or disable the onboard audio device.
Onboard LAN Function (Enabled)
Use this item to enable or disable the onboard LAN function.
Onboard LAN Boot ROM (Disabled)
Use this item to enable or disable the booting from the onboard LAN or a network
add-in card with a remote boot ROM installed.
Serial Port1/Port2/Port3 Address (Enabled / 2F8/IRQ3 / 3E8/IRQ4)
Use this item to enable or disable the onboard COM1/COM2/COM3 serial port, and
to assign a port address.
Parallel Port Address (378)
Use this item to enable or disable the onboard Parallel port, and to assign a port
address.
Parallel Port Mode (ECP)
Use this item to select the parallel port mode. You can select Normal (Standard
Parallel Port), ECP (Extended Capabilities Port), EPP (Enhanced Parallel Port), or BPP
(Bi-Directional Parallel Port).
: Move F10: Save ESC: Exit Enter : Select +/-/: Value
F9: Load Default Settings F1: General Help
Allow BIOS to
Enabled/Disabled
Audio Controller.
Press to return to the main menu setting page.
SATA Configuration (IDE)
Use this item to show the Serial ATA Configuration options: Disabled, Compatible,
Enhanced.
