4.10 Print Server
1. Install your Printer driver into your computer, (for example. if Epson PL-
6200L Printer is connected to the NAS, you must install PL-6200L driver in
to the computer first). After driver installation, please click “Start” →
“Setting” “ → Printer and Faxes” “ → Add a printer” “ → Next”.
2. Connect the USB printer in to NAS Dongle, your network environment
should looks like diagram below:
3. Select “Local printer” and click “next” to continue.
4. Select “Create a new port type of port:” , choose “Standard TCP/IP
Port”, and click “next” to continue.
5. Enter the NAS Dongle IP address than click “next” to continue.
6. Select “Custom” and go to “setting”.
7. Select LPR in protocol, and give a queue name eg:LRxxx; select LPR byte
enable and click “OK” to finish the port setting.
8. Click “Finish” to complete TCP/IP printer setup.
9. Go to Pinter server page and check printer server status. If status shows
“OK”, the printer is setting up successfully.
