Atlantis Land DISKMASTER NASF101 User Manual
Page 10
10
2.4 Front Panel and LEDs
LED
MEANING
Power
Lit blue if powered on.
Link
Flashes yellow when sending/receiving data.
TASTO
MEANING
Reset
Push RESET button for 30s to recovery default values on NAS
Dongle.
PORT
MEANING
Power Jack
Connect the supplied power adapter to this jack.
LAN
Please use the Ethernet cable to connect the Disk Master to
network.
USB
Please use the USB cable provided to connect an HDD
enclosure or the printer cable to connect the device’s USB port
(for printer server).
