Specifications
MAIN UNIT CX-NTR77
TUNER
FM tuning range 87.5 MHz to 108 MHz
FM usable sensitivity (IHF) 13.2 dBf
FM antenna terminal
75 ohms (unbalanced)
AM tuning range 530 kHz to 1710 kHz (10 kHz step)
531 kHz to 1602 kHz (9 kHz step)
AM usable sensitivity 350 µV/m
AM antenna Loop antenna
AMPLIFIER
Power output 120 W + 120 W (40 Hz - 20 kHz,
THD less than 1 %, 6 ohms)
150 W + 150 W (1 kHz, THD less
than 10 %, 6 ohms)
Total harmonic distortion 0.08 % (75 W, 1 kHz, 6 ohms, DIN
AUDIO)
Input VIDEO/AUX: 700 mV
Outputs SPEAKERS: 6 ohms or more
PHONES: 32 ohms or more
CASSETTE DECK
Track format 4 tracks, 2 channels stereo
Frequency response 50 Hz – 15 kHz
Recording system AC bias
Heads DECK 1: playback x 1
DECK 2: recording/playback x 1,
erase x 1
CD PLAYER
Laser Semiconductor laser (λ = 780 nm)
D/A converter 1 bit dual
Signal-to-noise ratio 85 dB (1 kHz, 0 dB)
Harmonic distortion 0.05 % (1 kHz, 0 dB)
GENERAL
Power requirements 120 V AC, 60 Hz
Power consumption 130 W
Power consumption With ECO mode on: 0.6 W
in standby mode With ECO mode off: 25 W
Dimensions (W x H x D) 260 x 324 x 391 mm
(10
1 / 4 x 12 7 / 8 x 15 1 / 2 in.)
Weight 8.7 kg (19 lbs 3 oz)
FRONT SPEAKERS SX-NTR77
Speaker system 3 way, bass reflex
Speaker units Woofer: 120 mm (4 3 / 4 in.) cone x 3
Tweeter: 60 mm (2 3 / 8 in.) cone
Super tweeter: 20 mm ( 13 / 16 in.)
ceramic
Impedance 6 ohms
Dimensions (W x H x D) 275 x 370 x 297 mm
(10
7 / 8 x 14 5 / 8 x 11 3 / 4 in.)
Weight 5.1 kg (11 lbs 4 oz)
Specifications and external appearance are subject to change
without notice.
COPYRIGHT
Check copyright laws relevant to recordings from discs, radio
or tape for the country where the unit is to be used.
