American Dryer Corp. ML-122 - Manual (Page 33)

450570-4 Telephone: (508) 678-9000 / www.amdry.com 31
Illus. No. Part No. Qty. Description
1 150009 2 #6-32 x 1-1/2” Phillips Pan Head Machine Screw
2 120701 1 4-Position Terminal Block
3 323743 1 Reversing Relay Panel
4 151000 2 #6-32 Pal Nut
5 152002 1 1/4-20 Hex Nut
6 153021 1 1/4” Lock Washer
7 121012 2 Ground Lug
8 135501 1 2-Pole 1-amp Circuit Breaker
9 150301 2 #8-18 x 7/16” Phillips Head TEK Screw
10 121502 3 1/2” Wire Standoff
11 132496 1 9-amp 2 hp Contactor with Coil Suppression
12 132497 1 Reversing Contactor with Coil Suppression
13 131932 1 Relay
14 152004 1 5/16-18 Hex Nut
15 153002 1 5/16” Lock Washer
16 153525 1 1/4-20 x 1” Self Clinching Stud
17 112075 1 Ground Label
* Not illustrated.
Reversing Relay Panel Assembly
For 60 Hz Electric Models Only
For Models Mfd. prior to March 2, 2006
