Liquid propane gas burner assembly – American Dryer Corp. ML-122 User Manual
Page 21
450570-4
Telephone: (508) 678-9000 /
www.amdry.com
19
Illus. No.
Part No.
Qty.
Description
1
816110
1
Burner Box Only
2
331291
1
Pipe Bracket
3
150309
2
#10-16 x 1/2” Phillips Right Hand Crimptite Screw
4
142821
1
3/4” x 36” Nipple
5
142601
1
3/4” Union
6
142710
1
3/4” x 4” Nipple
7
142504
1
3/4” x 90° Elbow
8
142734
1
3/4” x 5-1/2” Nipple
9
142753
1
1-1/4” to 3/4” Reducing Coupling
10
354030
1
Pipe Bracket (flat)
11
150309
2
#10-16 x 1/2” Phillips Right Hand Crimptite Screw
12
140026
1
Direct Spark Ignition 3/4” 24 VAC Redundant Gas Valve (natural gas)
140411
1
Liquid Propane Kit
13
332256
1
Liquid Propane (Burner Baffle)
14
150309
2
#10-16 x 1/2” Phillips Right Hand Crimptite Screw
15
331291
1
Gas Valve Pipe Bracket
16
141219
1
3-Port Manifold
17
140819
3
#30 Burner Orifice (liquid propane gas)
18
150309
4
#10-16 x 1/2” Phillips Right Hand Crimptite Screw
19
335031
1
Direct Spark Ignition Mount Manifold Rest
20
150309
6
#10-16 x 1/2” Phillips Right Hand Crimptite Screw
21
141136
3
Uginox Burner Tube
22
150309
7
#10-16 x 1/2” Phillips Right Hand Crimptite Screw
23
390709
1
Burner Tube Support Only
24
150309
2
#10-16 x 1/2” Phillips Right Hand Crimptite Screw
25
150309
6
#10-16 x 1/2” Phillips Right Hand Crimptite Screw
26
802801
1
Sail Switch Assembly
27
390708
1
Burner Box Cover Plate Only
28
150309
1
#10-16 x 1/2” Phillips Right Hand Crimptite Screw
29
331290
1
Ignitor/Flame-Probe Sight Hole Disc Only
30
151000
2
#6-32 Pal Nut
31
130201
1
330° Manual Reset Hi-Limit Only
32
150001
2
#6-32 x 1/2” Right Hand Machine Screw
33
821457
1
Hi-Limit Bracket
34
128914
1
Ignitor/Flame-Probe Assembly
35
150309
1
#10-16 x 1/2” Phillips Right Hand Crimptite Screw
Liquid Propane Gas Burner Assembly
