American Dryer Corp. ML-122 - Manual (Page 27)

450570-4 Telephone: (508) 678-9000 / www.amdry.com 25
Pneumatic Valve Assembly
Illus. No. Part No. Qty. Description
1 330987 1 Micro Valve Bracket
2 836002 1 Air Jet Solenoid
3 150111 2 1/4-20” Phillips Round Head Machine Screw
4 152014 2 1/4-20” Free Spin Wash Nut
5 151000 2 #6-32 Pal Nut
6 100472 1 1/4” x 1/8” Male Connector
7 150002 2 #6-32 x 1” Phillips Round Head Machine Screw
8 100520 1 1/8” N.P.T. Silencer (muffler)
9 143268 1 1/8” 90º Brass Straight Elbow
10 100472 1 1/4” x 1/8” Male Connector
11 143115 4 1/4” Poly-Flo Tubing (sold by the foot)
