INSTALLATION OF EMERGENCY LIGHTING CAGES
All specifications and information shown were current as of publication, and are subject to change without notice.
964145IS JULY 2007
INSTALLATION INSTRUCTIONS
1. Center the wire guard over existing appliance.
2. Mark and drill mounting holes.
3. Insert screws through clamps and tighten.
NOTE: Anchors and screws provided are for wall mounting. Other
fasteners may be required for mounting to metal enclosure or cabinet.
WIDTH
DEPTH
HEIGHT
STI 9641 & STI 9645
SIDE VIEW
STI 9641 & STI 9645
TOP VIEW
HEIGHT
TOP VIEW
STI-9644
SIDE VIEW
STI-9644
WIDTH
DEPTH
PART #
HEIGHT
WIDTH
DEPTH
STI-9641
10.7 (271)
14.6 (370)
4 (101)
STI-9644
8.7 (220)
17.75 (450)
5.25 (133)
STI-9645
13.75 (349)
21.6 (548)
5.9 (149)
NOTE: Dimensions measure: inches (mm)
Electronic warranty form at www.sti-usa.com/wc14
