Operation
11 F232215 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
Table 1
Table 1 (Continued)
Display Meaning
___F The first 3 digits are reserved for temperature reading, F indicates “degrees Fahrenheit”
FILL “Fill error” – machine did not fill to programmed water level within 10 minutes
dOOr “Door” opened during cycle
SHUt / door Machine user must “shut door” of the washer to allow the cycle to begin
CAnt / OPEn Control cannot unlock the door
CArd
Control will interpret the coin 2 input as a START signal from a Card Reader with no timing
max restriction, meaning the signal can last any amount of time once recognized
USH1 “Wash 1” segment
USH2 “Wash 2” segment
USH3 “Wash 3” segment
USH4 “Wash 4” segment
rIn1 “Rinse 1” segment
rIn2 “Rinse 2” segment
rIn3 “Rinse 3” segment
rIn4 “Rinse 4” segment (final rinse)
dOnE Cycle has concluded
drAI Drain selected for segment; also indicates in drain step during 2 speed version test cycle
---- Flashes for a period of time (for safety) after power up while keeping outputs OFF
dEn1 Denomination assigned for coin 1 input (example: .25 would mean a US quarter)
dEn2 Denomination assigned for coin 2 input (example: 100 would mean a US dollar)
