Operation
F232215 10 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
Display Indicators
Table 1
lists the various displays and what they
mean. The operator should become familiar with
these machine displays.
Display Meaning
tESt Diagnostic test cycle selected or enabled
SPIn Spin (extract) step
SUP1 Supply signal 1 (“S1” output), normally detergent
SUP2 Supply signal 2 (“S2” output), normally bleach
SUP3 Supply signal 3 (“S3” output), normally softener
SUP4 Supply signal 4 (“S4” output)
SUP5 Supply signal 5 (“S5” output)
SdLY Spin coast (motor coasts after high speed extract)
CFIL Cold Fill
HFIL Hot Fill
bFIL Warm Fill (cold + hot)
bLCH Control will also light “add bleach” indicator
PASS Variable-speed ONLY – balance “PASS” condition; shows in “test” cycle only
FAIL Variable-speed ONLY – balance “FAIL” condition; shows in “test” cycle only
bAL? Variable-speed ONLY – meaning: “Do you wish to enter balance detection test routine?”
CY__ Cycle number (followed by a space and number 1 through highest cycle number)
nor
n Normal agitation selected
gEnt Gentle (reduced) agitation selected
SPn1 Variable-speed ONLY – low spin speed (the lower of 2 spin speeds)
SPn2 Variable-speed ONLY – high spin speed (the higher of 2 spin speeds)
For Wash speed forward (during test cycle)
rEv Wash speed reverse (during test cycle)
dISt Variable-speed ONLY – distribution speed (during test cycle)
LO Low water level
n
Ed Medium water level
HI High water level
CEL Display all temperatures in degrees Celsius
FAr Display all temperatures in degrees Fahrenheit
___C The first 3 digits are reserved for temperature reading, C indicates “degrees Celsius”
Table 1 (Continued)
