Stewart Audio CVA100-2 - Manual (Page 22)

22
5 Technical Specifications
Output Power 100W x 2 @ 70.7V
Frequency Response (+0, -3 dB) 65Hz—20kHz
THD+N <0.1%
Signal-to-Noise Ratio >90dB
Input Sensitivity 1V (0 dBV)
Input Impedance (Bal/Unbalanced) 20k Ohms/10k Ohms
Current—Standby, Idle, 1/8 Power 0.01W/10W/35W
Amplifier Class D
Remote Volume 0-10V
External Mute Contact-closure
High-Pass Filter (Selectable) 65/85/150Hz
Input Connectors RJ45, Euro Block 3-pin,
3.5mm
Output Connectors Euro Block 2-pin, 3.5mm
Power Supply 85-265 VAC 50/60Hz
LED Indicators Power, Active, Signal, Clip
Controls Recessed Level Knobs
Construction Steel & Aluminum Chassis
Mounting Rack Mounting
Cooling Convection-Cooling
Dimensions
Height 1.75in (4.6cm)
Width 8.26in (20.6cm)
Depth 10.6in (27cm)
Weight 2.8 lbs (1.27kG)
Stewart Audio reserves the rate to change features and specifications without notice.
