PRODUCT DESCRIPTION
Motor:
Induction type, totally enclosed fan ventilated cooling*, continuously rated*, class ‘F’
insulation. Motors comply with IEC34-1. Single phase versions incorporate a permanent
capacitor and integral auto resetting thermal overload protection.
The standard range of motors are suitable for a supply of 230V, 1 phase, 50Hz.
Optional motors are available on certain models to suit various voltages and frequencies
(see technical specification for details).
*Variations of rating and enclosure details can be found in the technical specification
section.
Pump
All models are close coupled to motor.
RG4000 & 6000 are of single stage, peripheral design, with vertical suction and
discharge ports.
ES4000 & 6000 are of single stage, end suction, peripheral design.
Standard pump materials of construction of major wetted parts are as follows: -
* With footvalve fitted.
**Note: Max working pressure is the maximum pressure that can be applied to the
pump internal casing under any installation conditions.
Other seal material options are available on certain models.
LIMITS OF APPLICATION
Model
Body
Impeller
Shaft
Mechanical Seal
ALL
Brass
Brass
Stainless Steel
Nitril/Carbon
Ceramic/Stainless Steel
Model
Supply
Max.
Liquid
Temp.
o
C
Min.
Liquid
Temp.
o
C
Max.
Ambient
Air Temp
o
C
Max.
Suction
Lift (m)
Max. Head
(Pump
Closed
Valve) (m)
Max. Viscosity
**Max.
Working
Pressure
kPa (bar)
Max.
Inlet
Head
(m)
Max. No.
Starts/h
(Redwood No. 1
Scale)
Centistokes
RG300
230/1/50
80
4
40
4.6*
25.5
50
9.5
600 (6)
35
60
RG4000
230/1/50
80
4
40
4.6*
30.7
50
9.5
600 (6)
30
60
RG5000
230/1/50
80
4
40
4.6*
40
50
9.5
600 (6)
33
60
RG5000DV
230/1/50
80
4
40
4.6*
TBA
50
9.5
600 (6)
TBA
60
RG5000DV
230/1/60
80
4
40
4.6*
TBA
50
9.5
600 (6)
TBA
60
RG5000DV
110/1/50
80
4
40
4.6*
TBA
50
9.5
600 (6)
TBA
60
RG5000DV
110/1/60
80
4
40
4.6*
TBA
50
9.5
600 (6)
TBA
60
RG6000
230/1/50
80
4
40
4.6*
41.6
50
9.5
600 (6)
19
60
ES4000
230/1/50
80
4
40
4.6*
29.8
50
9.5
600 (6)
31
60
ES6000
230/1/50
80
4
40
4.6*
42.0
50
9.5
600 (6)
19
60
