PRODUCT DESCRIPTION
Electric motor driven single or twin ended centrifugal pump, complete with an automatic
control system, consisting of flow switches and electronic controls.
APPLICATION
These Techflow pumps are suitable for positive or negative head installation conditions.
The pumps are designed for whole house pressure boosting applications in vented stored
water systems. Inlet pressures to the pump and ambient temperatures must not exceed
the values given in the technical specifications.

This pump set must not be used for any other application without the
written consent of Techflow Products and in particular, MUST NOT be
connected directly to the mains water supply.
 This appliance is not intended for use by persons (including children)
with reduced physical, sensory or mental capabilities, or lack of
experience and knowledge, unless they have been given supervision
or instruction concerning use of the appliance by a person responsible
for their safety.
 Children should be supervised to ensure that they do not play with the
appliance.
Please read installation details carefully as they are intended to ensure this product
provides long, trouble free service. Failure to install the unit in accordance with the
installation instructions will lead to invalidation of the warranty.
STORAGE
If this product is not to be installed immediately on receipt, ensure that it is stored in a dry,
frost and vibration free location in its original packaging.
