- 13 -

Cont ...

4.21

Fuse: The following fuse size should be used with the appropriate pump:

Model

Fuse Size (AMPS)

All Models

3

4.22

Internal Wiring

Do not remove terminal box cover. This product is not serviceable.

4.23

Supply Cord Replacement

If the supply cord is damaged, it must be replaced by Stuart Turner
Ltd or by one of their approved repairers, or similarly qualified
persons in order to avoid a hazard.

4.24

Supply Cord Extension

The pumps are fitted with a supply cord to the following specification:-

HO3VV-F3 G 0.5 mm² - 3 Amp rated cable.

If the supply cord is to be extended, a cord of the same specification should be

used. Any connections or junction boxes used should be specifically suited for

the application and installed in accordance with the manufacturers instructions.
