Page 11
Adapters
Hose
Radiator
Green Hose
Black Hose
Radiator
Step
SYS TEM
PR ESS URE
EXC HAN
GE C
OO LAN T
TES
T
FILL RA DIA TOR
& O VER FLO
W
EM PTY
WA STE TAN
K
LOW
ER R
ADIA
TO R
& O VER FLO
W
Overflow
Water
Pump
OFF
OFF
SYS TEM
VA CU UM
& O VER FLO
W
LOW ER R
ADIA
TO R
EXC HAN
GE C
OO LAN T O R
FILL
RA DIA TO R & OV ERF LOW
EM PTY W AST E T ANK
Core
Engine
Block Heater
Adapter
Hose
OFF
EM PTY W AST E TA NK
EM PTY WA STE TA NK
& O VER FLO W
LOW ER RA DIA TO R
& O VE RFL OW
FILL RA DIA TO R
TES T
EXC HAN GE C OOL ANT
OFF
FILL RA DIA TO R & OV ERF LOW
EXC HAN GE C OO LAN T O R
LO WE R R ADIA TOR & O VER FLO W
SYS TEM VA CUU M
OFF
OFF
SYS TEM PR ESS UR E
TEST COOLANT SYSTEM FOR LEAKS
The MCX-2S can be used to check the coolant system for leaks. The coolant system
is pressurized and the System Pressure Gauge on the MCX-2S is monitored for a drop
in pressure which would indicate a system leak.
The MCX-2S should be connected a shown above.
1. Turn control valve to TEST.
2. Press the top of EXCHANGE COOLANT OR FILL RADIATOR & OVERFLOW
selector switch to turn on the pump.
3. Watch the System Pressure Gauge and press the bottom of the EXCHANGE
COOLANT OR FILL RADIATOR & OVERFLOW selector switch when the
pressure reaches 10 to 13 PSI.
4. The coolant system is now pressurized. Monitor the pressure for a constant
reading. A coolant system leak is indicated if the pressure falls.
