Pos. no. location – MAHLE RTI RHS700 User Manual
Page 26
- 14.2 -
Pos. no. location
C:\RHS Computer Files\Instructions\RHS\GB\645-40\0009A-01.doc 1997.03.26
RHS 700
Wiring diagram
M3: Vacuum
pump
Y14:
Solenoid valve
Y15: Solenoid
valve
Y16: Solenoid
valve
EH1: Heating
element
EH2: Heating
element
ST1: Thermostat
ST2:
Thermal protector (manual reset)
ST3: Thermostat
ST4:
Thermal protector (manual reset)
M1: Compressor
M2: Fan
Y9: Solenoid
valve
Y21: Solenoid
valve
SL2: Level
switch
Y8:
Solenoid valve
SP1: Pressure
control
SP2: Pressure
control
SP3: Pressure
control
SP4: Pressure
control
SP5:
Pressure control
