- 13.2 -
Specifications
C:\RHS Computer Files\Instructions\RHS\GB\645-40\0009A-01.doc 1997.03.26
RHS 700
Operating panel:
Mains switch - white:
Power supply cut in
Recovery switch - green:
Recovery process in function
Evacuation switch - green:
Evacuation process in function
Refrigerant charging switch - green:
Refrigerant charging in process
Vacuum check lamp - green:
Vacuum OK
Charging cylinder lamp - yellow:
Cylinder full
Service and maintenance
Filter drier 1:
Replaceable, 3/8" SAE
Filter drier 2:
Replaceable, 3/8” SAE (capacity 50 hours or 200
kg refrigerant)
Vacuum pump oil level:
Sight glass + charging stub
Safety equipment:
Mechanical safety valve on charging cylinder
Overfilling protection on charging cylinder
Suction pressure regulator on compressor
High-pressure control on compressor
Code number of RHS 700:
See nameplate
