<2. Configuring the Power and Energy Meter>
2-1
2. Configuring the Power and Energy Meter
2.1 Starting/Closing the Software and Showing
Version Information
Starting the Software
From the task bar, click Start, point to All programs > Powercert, and choose PC
parameter setting tool. The software starts.
Menu bar
Toolbar
Machine information
(for indication only)
Input parameters (for
the PR300 only)
Figure2.1
Model and Suffix Codes Screen (Example Screen of the PR300)
Closing the Software
From the File menu, choose Exit, or click the X button.
The configuration software window closes.
Showing Version Information
From the Help menu, choose About. You can also click the About icon ( ) on the
toolbar. The About dialog box opens.
Figure2.2 Version
Information
Click OK to close the About dialog box.
IM 77C01Y01-01E
