3-1 IM WX1-05E
1
2
3
Index
Deta
led Descr
pt
on Funct
ons
Chapter 3 Detaled Descrpton Functons
3.1 Overvew
GateMODBUS performs serial communications with Modbus devices and acquires data
at regular intervals. Through the monitor server function, the acquired data is transferred
to DAQLOGGER or Remote Monitor via Ethernet. The following is a list of the features
of each software function.
Envronment Settng Functons
Environment setting functions are used to enter all environment settings required to run
the executable function, and are also used to run/stop the executable function.
• Seral Port Settngs
Baud rate
Parity
• Ethernet port to be used
IP address or host name
Port number
• Data Acquston Condtons
Scan interval
Timeout time
Retries
• Tag Settngs
Communications port
Modbus address
Modbus function
Modbus register number
Modbus data type
Scaling coefficient
Scaling offset
Decimal place
Upper/lower limit of span
Unit
Tag name
• Group Settngs
Tag assignments
Tag colors
Group name
• TCP/IP Settngs for the Montor Server Port
• Runnng/Stoppng Executable Functon
Running of the executable function as a service
Running of the executable function as a process
Stopping the executable function
• Performng Tests (Data Acquston)
• Loop Back Test
• Communcaton Retry ON/OFF for the Executable Functon, Retry
Interval, and Reset
• Status Dsplay of Executable Functon
Practice status display (stopped, running as a service, running as a process)
The client connection status is displayed if DAQLOGGER or Remote Monitor is the
client.
