<2. Configuration>
2-1
IM 11B06F01-01E
2. Configuration
This chapter explains the configuration of the hardware and software of STARDOM FCN re-
quired for ASIU.
Refer to the General Specifications of STARDOM for details of each item.
2.1 Hardware configuration
The following type FCN is required for the ASIU.
l Specification Code
Specify these codes when ordering.
Model Name Item Remarks
NFBU200-S□□ Base module
NFCP100-S0□ CPU module
NFPW441-1□ Power module 100 to 120 V AC
NFPW442-1□ Power module 220 to 240 V AC
NFPW444-1□ Power module 24 V DC
NFDV151 Digital input module 32 points, 24 V DC
NFDV551 Digital output module 32 points, 24 V DC
NFDR541 Relay output module 16 points, 24 to 110 V DC /100 to 240 V AC
NFAI135 Analog input module 4 to 20 mA, 8 points, channel isolation
NFAI143 Analog input module 4 to 20 mA, 16 points, system isolation
NFDCV01 Dummy cover Cover for empty I/O module
NFDCV02 Dummy cover Cover for empty power module
2.2 Software configuration
ASIU
Model Suffix Code Option Code Description
ASIU ....................................... .................... Software Package
Function -A01 .................... Standard
Language E
J
....................
....................
English
Japanese
___ -N .................... Always "-N"
___ N .................... Always "N"
ASIU requires the license and software shown below.
License Code Item Remarks
NT711AJ-LS05A FCN/FCJ basic software license
for single CPU without Java
It is supplied by a system card.
NT8035J-LW11A Modbus communication portfolio
license
The license number is indicated
on the order ID sheet.
4th Edition : Nov. 22, 2011-00
