1 Introduction

This mower is built to the highest standards in the industry. However, carelessness or operator error may
result in serious bodily injury or death. Accident and hazard prevention are dependent upon the awareness,
concern, wisdom, and proper training of the personnel involved in the operation, transport, maintenance, and
storage of the equipment. Make sure every operator is properly trained and thoroughly familiar with all of the
information in this manual before operating the equipment.

This machine is constructed only for mowing grass on lawns without obstacles such as stones, tree stumps
etc. The machine can also be used for other tasks when equipped with special accessory attachments;
Grass Gobbler, Rear Bagging System and JRCO attachments. All other types of uses are incorrect. The
manufacturer’s directions concerning operation, maintenance, and repairs must be carefully followed.

Lawn mowers and all power equipment, can be potentially dangerous if used improperly. Safety requires
good judgment, careful use in accordance with these instructions and common sense.

The machine must only be operated, maintained and repaired by persons familiar with the machine’s special
characteristics and who are also knowledgeable about the safety instructions. Use only approved repair
parts to maintain.

Accident prevention regulations, other general safety regulations, occupational safety rules, and traffic
regulations must be followed without fail.

Unauthorized modifications to the design of the machine will absolve the manufacturer from liability for any
resulting personal injury or property damage.

This machine is not intended for use in extreme environments, as a tow vehicle, on steep slopes or in an
enclosed area without good ventilation.

1.1 Technical Data

Weight of overall machine

48” (122 cm) = 816 lbs (370 kg)
52” (132 cm) = 890 lbs (404 kg)
61” (155 cm) = 943 lbs (428 kg)

Machine dimensions

48” (122 cm) = 61.375” (155.9 cm) L x 49” *61” (124 cm *155 cm) W

*Chute deflector down

52” (132 cm) = 62” (157 cm) L x 53” *65” (135 cm *165 cm) W
61” (155 cm) = 64.375” (163.5 cm) L x 62” *74” (157 cm *188 cm) W

Speeds

Fwd. 9.5 mph (15.2 kmh), Rev. 5.5 mph (8.9 kmh)

Power supply

12V DC

1.2 General Safety Rules

The Wright Stander X is designed with your safety in mind. It has the following safety systems with which
you should become familiar:

The warning decals on the mower including the parking brake and general warning decal.

DO NOT disable any of the safety features.

The blade switch must be “off” before starting the engine.

You must be standing while feet are firmly on the platform to engage the blades.

If you step off of the platform while the blades are running the engine will stop and the blades will brake in

seconds.

Spring loaded chute deflector helps reduce trajectory of thrown objects.

Belt/Pulley covers on cutter deck.

Low center of gravity (CG) to improve stability on hills.
