12
Width, deflector down 61" (155 cm)
Width, deflector up
49" (124 cm)
Length 61.375" (156 cm)
Height 46.5" (118 cm)
Weight 816 lbs (370 kg)
Width, deflector down 65" (165 cm)
Width, deflector up
53" (135 cm)
Length 62" (157 cm)
Height 46.5" (118 cm)
Weight 890 lbs (403.7 kg)
Width, deflector down 74" (188 cm)
Width, deflector up
62" (157 cm)
Length 64.375" (164 cm)
Height 46.5" (118 cm)
Weight 943 lbs (427.7 kg)
48" Stander X
52" Stander X
61" Stander X
Critical Application
Thread
Locker
Torque Range
ft. lbs (Nm)
Engine mounting bolts Loctite 2760 45 ft lbs (61 Nm )
Wheel motor bolts (Securing motor to support) Loctite 2760 50 f t lbs (68 Nm )
Clutch to engine shaft Loctite 2760 50 ft lbs (68 Nm )
Wheel hub to wheel motor N/A 140 ft lbs (190 Nm )
Wheel lug nuts N/A 80 ft lbs (108 Nm )
Split Hub (Spindle & Drive) (Gr 8) N/A 14 ft lbs (19 Nm )
Blade Bolts N/A 75 ft lbs (102 Nm )
Torque Specifications
Fuel System
•
Capacity: 5.6 Gal. (21 L)
•
Type of Fuel: Unleaded regular gasoline, minimum 85 octane. Do not use gasoline containing
more than 10% ethanol. Do not mix oil with gasoline.
•
Fuel Filter: In line
•
Fuel shut off: On, Off located on fuel tank
Safety Interlock System
•
PTO switch must be disengaged, brake engaged and the control handles in the neutral and
locked position to start the engine.
•
Operator must have feet on the platform to engage the PTO and brake off or engine will stop.
Drive System:
•
Two Hydro Gear 12cc w/fans variable displacement piston pumps
•
Two Hydro Gear 15cu in. wheel motors
Hydro Oil System
•
Hydro Oil: fully SYNTHETIC motor oil: Mobil-1 15W-50
•
Hydro Filter: Spin-on, 25 micron, no bypass / PN 34490002
•
Total Capacity: 3 qts
•
Tank Fill Level: Fill until fluid comes from fill port.
