20 WATLOW Series 942 How to Use Data Communications
Commands
Table 5 -
Continued
Data.1 Data.2
Low Limit High Limit Code Function
IN 0 12 0 J T/C
1 K T/C
2 T T/C
3 N T/C
4 PT2 T/C
5 C T/C
6 Not Used
7 R T/C
8 S T/C
9 B T/C
10 RTD whole
11 RTD tenths
12 0-5V
13 4-20mA
ITX 0.00 9.99 Output X Integral
LATX 0 1 0 Latched alarms
1 Non-latched alarms
LOC 0 3 Front panel lockout
LOG 0 1 0 Logging OFF
1 Logging ON
See Page 21.
OFF 0 1 0 Hold
1 OFF
OUT 0 3 0 Heat/Cool (output 1 & 2)
1 Cool/Heat
2 Heat/no action
3 Cool/no action
OT3 or 4 0 2 or 4* 0 Alarm
1 Event
2 No action
3* Process Retransmit
4* Set Point Retransmit
*only applies to Ot4
PBX 0 999°F Output X
555°C Proportional Band
999 Units
POUT 0 3 0 Continue
1 Hold
2 Abort
3 Reset
PSTR 0 1 0 Process
1 Set Point
PTYP 0 1 0 Time Based
1 Rate Based
RAX 0.00 9.99 Output X Rate
REX 0.00 9.99 Output X Reset
RH Min. IN range Max. IN range Range High
RL Min. IN range Max. IN range Range Low
RTD 0 1 0 DIN
1 JIS
SIL 0 1 0 Alarm silence OFF
1 Alarm silence ON
SP1 RL RH Set point
