Application 24
Automatic Timer
Introduction to Application 24 . . . . . . . . . . . . . . 1
Configuration Mode Quick Reference . . . . . . . . . 3
Program Mode Quick Reference . . . . . . . . . . . . 4
Step 7 Design a Faceplate Overlay . . . . . . . . . . . 5
Step 8 Operate the Controller . . . . . . . . . . . . . . 6
Application 24 allows you to program six concurrent timers.
Overview of Key Steps
1. Install the M INI C HEF 2000.
2. Wire the controller.
3. Configure the controller.
4. Program the menus.
5. Set the controller security.
6. Set the Real-time Clock.
For instructions on Steps 1, 2, 3, 4, 5 and 6, see the Hardware & Software Setup Guide.
7. Design, manufacture and apply faceplate overlay for end-users. (For a suggested design
to suit this application, see this section. For overlay dimensions and guidelines, see the
Hardware & Software Setup Guide.)
8. Operate the controller. (See this application guide.)
24
