WATLOW DIN-A-MITE Style B User's Manual
General Specifications
Operator Interface
• Command signal input and indication light
• Alarm output and indication light
• Input indicator LED
Amperage Rating
• See the output rating curve chart on page 3.
• Ratings are into a resistive heater load.
• Maximum surge current for 16.6 milliseconds, 380 A
peak
• Maximum I 2 t for fusing is 4000 A 2 s
• Latching current: 200mA minimum
• Holding current: 100mA minimum
• Off-state leakage 1mA at 25°C (77°F) maximum
• Power Dissipation: 1.2 watts per amp switched
• 200KA SCCR type 1 and 2 approved with the
recommended fusing (see page 3)
Line Voltage
• 24 to 48V~ (ac) units: 20.4V~ minimum to 53V~
maximum
• 120 to 240V~ (ac) units: 48V~ minimum to 265V~
maximum
• 277 to 600V~ (ac) units: 85V~ minimum to 660V~
maximum
Control Mode, Zero-Cross
• Input Control Signal Type C: V
Î (dc) input contactor.
To increase service life, the cycle time should be less
than 3 seconds.
• Input Control Signal Type K: V~ (ac) input contactor.
To increase service life, the cycle time should be less
than 3 seconds.
• Input Control Signal Type F: 4 to 20mA Î (dc)
proportional variable time base control.
Input Command Signal
• AC contactor
24V Å ±10%, 120V Å +10%/-25%, 240V Å (ac)
+10%/-25% @ 25mA maximum per controlled leg
• Do not use the DIN-A-MITE Vac-input models with a
temperature controller that includes an RC snubber
circuit across its output. Remove the RC snubber
circuit before placing the DIN-A-MITE into service.
• DC Contactor
4.5V Î to 32V Î (dc): maximum current @ 4.5V Î (dc)
is 6mA per leg, plus 2mA per LED used.
• Loop powered linear current
4mA Î to 20mA Î (dc): loop-powered. Input Type
F0 option only. (Requires current source
with 6.2V
Î (dc) available. No more than three
DIN-A-MITE inputs connected in series)
Linearity (Input Control Signal Type F)
• Full on point 19.5 to 19.9mA
Î (dc), maximum voltage
of 6.2V peak.
• ±5% input to output power accuracy, 0% to 100% of
span (4.3 to 19.7mA).
• Temperature stability is less than 0.15%/°C change.
Alarm (not available on multizone models)
Shorted SCR Alarm Option
• Alarm state when the input command signal off and a
10 A or more load current is detected by the current
transformer (two turns required for 5A and three turns
for 2.5A).
Alarm output
• Energizes on alarm, non-latching
• Triac 24 to 240V~ (ac), external supply with a current
rating of 300mA @ 25°C (77°F), 200mA @ 50°C
(122°F), 100mA @ 80°C (176°F) and a holding
current of 200µA with a latching current of 5mA
typical.
Agency Approvals
• CE with proper filter:
2004/108/EC Electromagnetic Compatibility Directive
EN 61326: Industrial Immunity Class A emissions
2006/95/EC Low Voltage Directive
EN 50178 Safety Requirements
Installation category III, pollution degree 2
• UL ® 508 listed and C-UL ® , File E73741
Input Terminals
• Compression: Will accept 0.2 to 1.5 mm
2 (24 to 16
AWG) wire
• Torque to 0.5 Nm (4.4 in-lb) maximum with a 3.5 mm
(1/8 in) blade screwdriver
• Wire strip length 5.5 mm (0.22 in)
Line and Load Terminals
• Compression: Will accept 0.75 to 10 mm2 (18 to 8
AWG) wire
• Torque to 1.4 Nm (12 in-lb) with a 6.4 mm (1/4 in)
blade screwdriver, or a Type 1A #2 Pozi driver.
• Retorque after 48 hours to minimize wire cold flow.
• Retorque line and load terminals every 3 to 6 months.
• Wire strip length 6.35 mm (0.25 in)
• Ground terminal use spade terminal for No. 8 screw,
with upturned lugs.
Operating Environment
• See the output rating curve.
• 0 to 90% RH (relative humidity), non-condensing
• Storage temperature: -40 to +85°C (-40 to 185°F)
• Insulation only tested to 3,000 meters
DIN Rail Mount
• DIN EN 50022, 35 mm by 7.5 mm
• Minimum clipping distance: 34.8 mm (1.37 in)
• Maximum clipping distance: 35.3 mm (1.39 in)
Note: Mount cooling fins vertically.
Back Panel Mount
• Four mounting holes M4 (No. 8) fastener
Weight
• 0.7 kg (1.6 lb)
Specifications are subject to change without notice.
