10
WATLOW DIN-A-MITE Style B User's Manual
Declaration of Conformity
DIN-A-MITE
®
“B” Power Controller
WATLOW an ISO 9001 approved facility since 1996.
1241 Bundy Blvd.
Winona, MN 55987 USA
Declares that the following product:
Designation: DIN-A-MITE ® “B” Power Control
Model Numbers: DB (1, 2, 3, 4, 8 or 9) 0 – (02, 24 or 60)(CX, FX, K1, K2, K3) – (0 or S)(followed by
any 3 letters or numbers) (where X = any number 0-9)
Classification: Power Control, Installation Category III, Pollution degree 2, IP20
Rated Voltage: 24 to 600 V~ (ac), 50/60 Hz
Meets the essential requirements of the following European Union Directives by using the relevant
standards show below to indicate compliance.
2004/108/EC Electromagnetic Compatibility Directive
EN 61326-1: 2005 Electrical equipment for measurement, control and laboratory use
– EMC requirements (Industrial Immunity, Class A 1,2,4 Emissions)
Not for use in a Class B environment without additional filtering.
EN 61000-4-2:12008 Electrostatic Discharge Immunity
EN 61000-4-3:2006 Radiated Field Immunity 10V/m 80 MHz- 1GHz, 3V/m 1.4GHz-2.7GHz
EN 61000-4-4:2011 Electrical Fast-Transient / Burst Immunity
EN 61000-4-5:2006 Surge Immunity
EN 61000-4-6:2008 Conducted Immunity
EN 61000-4-11:2004 Voltage Dips, Short Interruptions and Voltage Variations
EN 61000-3-2:2005 Harmonic Current Emissions
EN 61000-3-3:2005
EN 61000-3-11:2001
Voltage Fluctuations and Flicker 3 ≤ 16A
Voltage Fluctuations and Flicker ≤ 75A with conditional connection
NOTES
1 Use of an external filter is required to comply with conducted emissions limits. See note 4 below.
2 A Line Impedance Stabilization Network (LISN) was used for conducted emissions measurements.
3 To comply with flicker requirements, command signal models F0 and F1 will require a reduced source
impedance. Cycle time on ON/OFF models CX and K1, K2, K3 may need to be up to 175 seconds at 16A
or have a reduced source impedance.
2006/95/EC Low-Voltage Directive
EN 50178:1997 Electronic equipment for use in power installations.
Per 2002/96/EC W.E.E.E Directive Please Recycle Properly.
These devices contain lead solder and are not RoHS compliant.
They are a Control Device and fall outside the scope of 2002/95/EC Directive.
4 Required External EMI Filters for DIN-A-MITE with More Than 6 Amp Loads
An external ElectroMagnetic Interference (EMI) filter must be used in conjunction with the DIN-A-
MITE for loads in excess of six amperes (6A) at 150 to 250 KHz.
Watlow has verified that a tank filter will suppre
ss EMI created by SCR power controllers to comply
with the conducted emissions limits.
