WATLOW DIN-A-MITE Style A User's Guide
7
DIN-A-MITE ® “A” Power Controller
WATLOW
1241 Bundy Blvd.
Winona, MN 55987 USA
Declares that the following products:
Designation: DIN-A-MITE® “A” Power Control
Model Numbers: DA10 – (02, 24 or 60)(C0, C1, C2, K1, K2, K3, F0 or F1) – 0 (followed by any 3 numbers or letters.)
Classification: Power Control, Installation Category III, Pollution degree 2, IP20
Rated Voltage: 24 to 600 V~ (ac), 50 or 60 Hz
Meets the essential requirements of the following European Union Directives by using the relevant standards show below to indicate
compliance.
2004/108/EC Electromagnetic Compatibility Directive
EN 61326-1: 2005 Electrical equipment for measurement, control and laboratory use
– EMC requirements (Industrial Immunity, Class A 1,2,4 Emissions)
Not for use in a Class B environment without additional filtering.
EN 61000-4-2:2008 Electrostatic Discharge Immunity
EN 61000-4-3:2006 Radiated Field Immunity 10V/m 80 MHz- 1GHz, 3V/m 1.4GHz-2.7GHz
EN 61000-4-4:2011 Electrical Fast-Transient / Burst Immunity
EN 61000-4-5:2006 Surge Immunity
EN 61000-4-6:2008 Conducted Immunity
EN 61000-4-11:2004 Voltage Dips, Short Interruptions and Voltage Variations
EN 61000-3-2:2005 Harmonic Current Emissions
EN 61000-3-3:2005 Voltage Fluctuations and Flicker 3
Notes
1 Use of an external filter is required to comply with conducted emissions limits. See note 4 below.
2 A Line Impedance Stabilization Network (LISN) was used for conducted emissions measurements.
3 To comply with flicker requirements, command signal models F0 and F1 will require a reduced source impedance. Cycle time on
ON/OFF models C0, C1, C2 and K1, K2, K3 may need to be up to 175 seconds at 16A.
2006/95/EC Low-Voltage Directive
EN 50178:1997
Electronic equipment for use in power installations.
Per 2002/96/EC W.E.E.E Directive Please Recycle Properly.
These devices contain lead solder and are not RoHS compliant.
They are a Control Devices and fall outside the scope of 2002/95/EC Directive.
4 Required External EMI Filters for DIN-A-MITE with More Than 6 Amp Loads
An external ElectroMagnetic Interference (EMI) filter must be used in conjunction with the DIN-A-MITE for loads in excess of six
amperes (6A) at 150 to 250 KHz.
Watlow has verified that a tank filter will suppress EMI created by SCR power controllers to comply with the conducted emissions
limits.
an ISO 9001approved facility since 1996.
