P B X D - S S S E R I E S E N C L O S U R E S
N E M A 1 2 & 1 3 ( 3 0 . 5 M M ) P U S H B U T T O N W A L L - M O U N T
E5
14 GA.
L
Ø 0.25 TYP
Ø 1.20 TYP
0.19 TYP
Standard 4-Way
Pushbutton
0.67 TYP
W >= 6.25"
HINGES PROVIDED WHEN
PBXD Hole Arrangements
PBXD4SS PBXD3SS PBXD2SS PBXD1SS
0.56 I
M
F
D
H
1.63
C
B
2.25
2.25
2.25
A 2.25 2.25
E
W
PBXD16SS
