R H C S E R I E S E N C L O S U R E S
“ S M A L L ” N E M A 3 R H I N G E C O V E R W A L L - M O U N T
B5
0.31 TYP
0.91
A
0.31 TYP
0.19
B
1.00 TYP ALL KO'S
D
C E H
W
(PATTERNS ARE CENTERED IN WIDTH)
3
0.44 INSIDE
F = 3/4" X 1" CONCENTRIC KO
G = 1/2" X 3/4" CONCENTRIC KO
H = 1" SOLID KO
I = 1-1/4" SOLID KO
KNOCKOUT PATTERN
G I H G F
1.63 1.94 1.63 1.63
HINGE
CONTINUOUS
DOOR LATCH
PADLOCKING
QUICK RELEASE
(ORDER SEPARATELY)
OPTIONAL SUB PANEL
SLOT TYP
0.31 X 0.56 MOUNTING
