APPENDIX
“G”
13
Manufacturer's Part Number
Description
Onboard spare parts proposal
Onshore spare parts proposal
Required Storage Space
323600-3
Crown Gear
1
350x350x50mm
327600-1
Swivel, Bearing Sleeve
1
130x130x150mm
327600-4
Bearing
1
110x110x100mm
390305
Snap Ring, 2.934" O.D. X .094 TK (2.55 I.D.)
2
4
70x70x2mm
S211-332
O-Ring, 2-3/8" X 2-3/4" X 3/16"
6
1
2
65x65x5mm
S211-331
O-Ring, 2-1/4" X 2-5/8" X 3/16"
2
4
65x65x5mm
S200-230
O-Ring, 2-1/2" X 2-3/4" X 1/8"
2
4
140x140x130mm
327600-2
Swivel, Outlet 2"
1
100x130x150mm
327600-3
Elbow, Discharge
1
120x90x45mm
360600-2
Bearing Assembly
1
140x140x130mm
327600-5
Swivel, Spindle
1
125x125x250mm
360600-6E
Hand Rewind Assembly
1
440x220x30mm
365600-1
Hand Crank
1
250x100x20mm
360600-4
Bracket & Nylon Strap
1
145x235x245mm
SFL-GN-95
Nozzle w/ Pistol Grip - 90 GPM @ 100 PSI
1
245x230x140mm
SFL-GN-125
Nozzle w/ Pistol Grip - 125 GPM @ 100 PSI
1
245x230x140mm
360700-125
Hose Assembly 1-1/2" X 125' (38m) w/ Couplings
1
1300x1300x200mm
360700-150
Hose Assembly 1-1/2" X 150' (46m) w/ Couplings
1
1300x1300x200mm
The following is an on-board spare parts list recommended for vessels carrying 1-10 AFFF reels. For larger vessels, carrying
more than 10 reels, it is
recommended that these ratios be maintained (round all fractions of parts up).
Provisioning Documentation Technical Data
