Series B4000 / B5000 Spring Driven Hose Reels

www.reelcraft.com

Page 3

Item

#

Description

#

Req.

B5835 OLP

B5850 OLP

B5435 OMP

B5630 OMP

B5835 OMP

B5435 OHP

B5625 OHP

1 Swivel

1

S600915

602032

602032

602032

602032

600602-1

600602-1

2 Swivel Union

1

300010

300010

S257-25

S257-25

S257-26

S257-2

S257-2

3 Swivel Union

1

300010

300010

S257-72

S257-72

S257-26

S257-2

S257-2

4 1/4-10 Self Tapping Screw

3

S295-102

S295-102

S295-102

S295-102

S295-102

S295-102

S295-102

5 Sheave Flange

1

260022

260149

260022

260022

260149

260149

260022

6 Sheave Disc

1

500006

260151

500006

500006

260151

260151

500006

7 1” External Snap Ring

1

300031

300031

300031

300031

300031

300031

300031

8 1” I.D. Spacing Washer

2

300034

300034

300034

300034

300034

300034

300034

9 Ratchet Arbor

1

262008

262008

262008

262008

262008

262008

262008

10 10-32 x 3/8 Machine Screw

Noted 300001 (6)

300001 (6)

300001 (5)

300001 (6)

300001 (6)

300001 (6)

300001 (6)

11 Base Assembly

1

500101

602505

500101

500101

602505

602505

500101

12 Drive Spring Assembly

1

S505740

S600050

S503755

S503755

S600620

S600620

S507287

13 Main Shaft & Snap Ring Assembly 1

602305

262569

602305

602305

602305

602306

602306

14 Spring Case Assembly

1

S500103

S600094

S500103

S500103

S600094

S600094

S500103

15 10-32 Sarrated Hex Lock Nut

Noted 300011 (8)

300011 (8)

300011 (7)

300011 (7)

300011 (10)

300011 (8)

300011 (7)

16 3/8-16 x 1/2 Set Screw

1

300006

300006

300006

300006

300006

300006

300006

17 Spring Case Stud

1

S261360

S261360

S261360

S261360

S261360

S261360

S261360

18 10-32 x 1/2 Machine Screw

2

300002

300002

300002

300002

300002

300002

300002

19 Hose Assembly

1

601020-35

601022-50

33-260043

16-260043

37-260043

20-260044

13-260044

20 Hose Bumper Assembly

1

A2-HR1004-3 2-HR1004-3

1-HR1004-A

1-HR1004-3

2-HR1004-3

1-HR1004

2-HR2004-3

21 Guide Arm Assembly

1

S602547

S602548

S602547

S602547

S602548

S602548

S602547

22 1/4-20 Hex Flange Lock Nut

2

261650-1

261650-1

261650-1

261650-1

261650-1

261650-1

261650-1

23 U-Bolt

1

3-117440

3-117440

3-117440

3-117440

3-117440

3-117440

3-117440

Dimension - Size Index #

3

3

2

2

3

3

2
