Series B4000 / B5000 Spring Driven Hose Reels

Page 2

www.reelcraft.com

Item

#

Description

#

Req.

B4425 OLP

B4435 OLP

B5450 OLP

B4625 OLP

B5635 OLP

B5650 OLP

B5825 OLP

1 Swivel

1

S600886

S600886

S600886

S600886

S600886

S600886

S600915

2 Swivel Union

1

None

None

None

None

None

None

300010

3 Swivel Union

1

None

None

None

None

None

None

300010

4 1/4-10 Self Tapping Screw

3

S295-102

S295-102

S295-102

S295-102

S295-102

S295-102

S295-102

5 Sheave Flange

1

400005

400005

260022

400005

260022

260149

260022

6 Sheave Disc

1

400006

400006

500006

400006

500006

260151

500006

7 1” External Snap Ring

1

300031

300031

300031

300031

300031

300031

300031

8 1” I.D. Spacing Washer

2

300034

300034

300034

300034

300034

300034

300034

9 Ratchet Arbor

1

262008

262008

262008

262008

262008

262008

262008

10 10-32 x 3/8 Machine Screw

Noted 300001 (5)

300001 (5)

300001 (6)

300001 (6)

300001 (5)

300001 (6)

300001 (6)

11 Base Assembly

1

400101

400101

500101

400101

500101

602505

500101

12 Drive Spring Assembly

1

S400030

S400030

S503755

S404230

S504240

S600050

S505740

13 Main Shaft & Snap Ring Assembly 1

602555

602555

602555

602555

602555

602555

602305

14 Spring Case Assembly

1

S400103

S400103

S500103

S400103

S500103

S600094

S500103

15 10-32 Sarrated Hex Lock Nut

Noted 300011 (7)

300011 (7)

300011 (7)

300011 (7)

300011 (7)

300011 (8)

300011 (7)

16 3/8-16 x 1/2 Set Screw

1

300006

300006

300006

300006

300006

300006

300006

17 Spring Case Stud

1

S261360

S261360

S261360

S261360

S261360

S261360

S261360

18 10-32 x 1/2 Machine Screw

2

300002

300002

300002

300002

300002

300002

300002

19 Hose Assembly

1

601001-25

601001-35

601001-50

601013-25

601013-35

601013-50

601020-25

20 Hose Bumper Assembly

1

1-HR1004-A A1-HR1004-A 1-HR1004-A

1-HR1004

A1-HR1004

1-HR1004

2-HR1004-3

21 Guide Arm Assembly

1

S602546

S602546

S602547

S602546

S602547

S602548

S602547

22 1/4-20 Hex Flange Lock Nut

2

261650-1

261650-1

261650-1

261650-1

261650-1

261650-1

261650-1

23 U-Bolt

1

3-117440

3-117440

3-117440

3-117440

3-117440

3-117440

3-117440

Dimension - Size Index #

1

1

2

1

2

3

2
