If the F2 key was pressed then the servo will be in the auto total mode and the
following screen appears.
AUTOMATIC FL=000.000
JOB #=00 SEQ=00 REP=00
TOTAL COUNTER=000000
F4=EXIT AUTO CYCLE
Pressing the F4 key, stops the automatic cycle and the main menu screen appears.
MAIN MENU
F1=JOB # F2=MANUAL
F3=AUTOMATIC CYCLE
F4=REVIEW JOB PROGRAM
F3=AUTOMATIC CYCLE
If the feed has been properly set up, tested in manual, press electrically interlocked
with feed, feed and pilot switches wired to the correct terminals, then pressing the F3
key will display the following screen.
SELECT CONTINUOUS OR
BATCH CYCLE F1=BATCH
F2=CONTINUOUS CYCLE
F4=EXIT TO MAIN MENU
F1=BATCH
If the F1 key was pressed then the servo will be in the auto batch mode and the
following screen appears.
BATCH SETTING=000000
BATCH COUNTER=000000
F1=RESET BATCH COUNT
F4=COINTINUE WITH COUNT
If F1 (reset batch count) is pressed then the batch count will be reset to it’s preset
valve. If F4 (continue with count) is pressed the batch count will remain at its present
value. Either F1 or F4 will lead to the following screen.
AUTOMATIC FL=000.000
JOB #=00 SEQ=00 REP=00
BATCH COUNTER=000000
F4=EXIT (AUTO CYCLE)
