Rapid-Air SERVO FEED GAG FEED: 950 SERIES User Manual

Page 22

Pressing the F4 key once will reset the program to the jog mode screen so that jog is
now active. Pressing the F4 key twice will reset the program to the manual mode
screen. If the F4 key was pressed twice then the following screen is displayed

MANUAL MODE F1=INCH
F2=SINGLE FEED MODE
F4=EXIT MANUAL MODE
CYCLE ROLL WITH KEYS

F2=SINGLE FEED

If the operator presses F2 then the following screen is displayed. The single feed mode
is active and every time the F1 key is pressed then the feed will cycle and move the
distance indicated on the feed length line.
JOB#=000 FL=000.000
SEQUENCE=00 REP’S=00
F1=FEED SINGLE LNGTH
F4=EXIT (MANUAL MODE)

Pressing F4 once resets the program to the manual mode display. Pressing the F4 key
twice resets the program to the main menu display. If the F4 key was pressed twice
the following screen is displayed.

MAIN MENU
F1=JOB # F2=MANUAL
F3=AUTOMATIC CYCLE
F4=REVIEW JOB PROGRAM

F3=AUTOMATIC CYCLE

If the feed has been properly set up, tested in manual, press electrically interlocked
with feed, feed and pilot switches wired to the correct terminals, then pressing the F3
key will display the following screen.

START AUTOMATIC FROM
F1=SEQUENCE NUMBER 1
F2=PREVIOUS SEQUENCE

After selecting one of the above choices the following screen appears.

SELECT CONTINUOUS OR
BATCH CYCLE F1=BATCH
F2=CONTINUOUS CYCLE
F4=EXIT TO MAIN MENU
F2=CONTINUOUS
