8
6. Remove output coupling (item #6) and coupling shaft (item #4) from end bearing (item #8). Examine bearings (item
#12), pressed in output coupling, for signs of wear. Replace bearings, if necessary, by pressing old bearings from
coupling and press new bearings (item #12) into each end of output coupling (item #4). Place coupling shaft (item
#6) into bearings (item #12).
7. Remove (12) capscrews (item #15) to pull gear housing cover (item
#3) from gear box (item #48). Remove input thrust washer, sun
gear and carrier assemblies from inside of ring gear. Remove ring
gear from end bearing (item #8). Examine shifter shaft (item #11)
for signs of wear, replace if necessary. Examine bushing (item #13)
for signs of wear. Replace bushing, if necessary, by pressing old
bushing from housing and pressing new bushing into place.
12 8
12
4
6
13
15
8
11
35
48
35
3
47
