PARTS LIST RPH 12,000T WITH BLOCKED CLUTCH
ITEM QTY. PART NO. DESCRIPTION
1
1 93758
DRUM ASS'Y.
2
1
306042
PISTON-BRAKE
3
1 338300
END BEARING-MOTOR
4
1 338301
END BEARING-GEAR HOUSING
5
1
338302
HOUSING-BRAKE
6
4
346045
PIN-BRAKE
7
1 357504
SHAFT-INPUT/SUN GEAR
8
2 395172
TIE PLATE
9
1 402120
BEARING-GEAR HSG.
10
1 402121
BEARING-MTR. END BEARING
11
1 412084
BUSHING-DRUM (MTR. END)
12
1 412085
BUSHING-DRUM (G.HSG. END)
13
6 414303
CAPSCREW-3/8-16NC X 2-1/2 LG. HX.HD., GR. 5 PLTD.
14
2
414948
CAPSCREW 1/2-13NC X 1-1/4 LG. SOC.HD.
15
8
414581
CAPSCREW 1/2-13NC X 3/4 LG. HX.HD. GR.5 PLTD.
16
2
414854
CAPSCREW 1/4-20NC X 1/2 RD.HD. SLOT PLTD.
17
4
414868
CAPSCREW 5/16-18NC X 1-1/2 LG. SOC. HD. NYLOK
18
1 414926
SETSCREW-3/8-16NC X 1 LG., SOCKET, NYLON
19
1
416016
SETSCREW-1/4-20NC X 1/4 LG., HX. SOC. HD.
20
1
416080
SETSCREW 5/8-18NF X 1 LG. HX.SOC.HD.
21
1
418036
NUT 3/8-16NC HEX. JAM
22
1
418088
NUT 5/8-18NF
23
2 418218
LOCKWASHER-1/2 ID MED. SECT.
24
1
426048
PLUNGER
25
1
431015
COUPLING-MOTOR
26
2
432018
FITTING-7/16 ELBOW
27
NOT USED
28
4
438022
DISC-BRAKE
29
1
442220
GASKET-BRAKE
30
1 442223
GASKET-MOTOR
31
1 444085
GEAR-RING
32
1
456038
FITTING-VENT
33
1
458090
MOTOR-HYDRAULIC
34
1 462046
O-RING (DRUM)
35
1
462056
O-RING
36
1
462057
O-RING
37
1
462058
O-RING
38
1
462059
O-RING BACKUP
39
1
462060
O-RING BACKUP
40
1
472052
PLUG
41
5 474111
PLATE-SEPARATOR
42
1 486080
SEAL-GEAR HSG.
43
1
490037
SNAP RING
44
6
494110
SPRING-BRAKE
45
4
494112
SPRING
46
1
509009
TUBE ASSEMBLY
47
1 516013
VALVE-MOTOR CONTROL
48
1
518037
THRUST WASHER
49
1
518047
THRUST WASHER
50
1
518052
THRUST WASHER
51
1
416059
SETSCREW-3/8-16NC X ½ HX SOC HD CUP
