PARTS LIST RPH 12,000T WITH AIR-CYLINDER CLUTCH SHIFTER
ITEM QTY. PART NO. DESCRIPTION
1
1 93758
DRUM ASS'Y.
2
1
236020
LIGHT ASSEMBLY
3
1 276053
SHIFTER ASS'Y.-AIR CYLINDER
4
1
306042
PISTON-BRAKE
5
1
312529
BRACKET-LIGHT
6
1 338300
END BEARING-MOTOR
7
1 338301
END BEARING-GEAR HOUSING
8
1
338302
HOUSING-BRAKE
9
4
346045
PIN-BRAKE
10
1 357504
SHAFT-INPUT/SUN GEAR
11
2 395172
TIE PLATE
12
1 402120
BEARING-GEAR HSG.
13
1 402121
BEARING-MTR. END BEARING
14
1 412084
BUSHING-DRUM (MTR. END)
15
1 412085
BUSHING-DRUM (G.HSG. END)
16
2
414036
CAPSCREW 1/4-20NC X 1/2 LG.
17
6 414303
CAPSCREW 3/8-16NC X 2-1/2 LG. HX.HD., GR. 5 PLTD.
18
2
414948
CAPSCREW 1/2-13NC X 1-1/4 LG. SOC.HD.
19
8
414581
CAPSCREW 1/2-13NC X 3/4 LG. HX.HD. GR.5 PLTD.
20
4 414868
CAPSCREW 5/16-18NC X 1-1/2 LG. SOC. HD. NYLOK
21
1 414926
SETSCREW-3/8-16NC X 1 LG., SOCKET, NYLON
22
1
416016
SETSCREW-1/4-20NC X 1/4 LG., HX. SOC. HD.
23
1
418036
NUT 3/8-16NC HEX. JAM
24
2 418218
LOCKWASHER-1/2 ID MED. SECT.
25
1
431015
COUPLING-MOTOR
26
2
432018
FITTING-7/16 ELBOW
27
NOT USED
28
4
438022
DISC-BRAKE
29
1
442220
GASKET-BRAKE
30
1 442223
GASKET-MOTOR
31
1 444085
GEAR-RING
32
1
456038
FITTING-VENT
33
1
458090
MOTOR-HYDRAULIC
34
1 462046
O-RING (DRUM)
35
1
462056
O-RING
36
1
462057
O-RING
37
1
462058
O-RING
38
1
462059
O-RING BACKUP
39
1
462060
O-RING BACKUP
40
5 474111
PLATE-SEPARATOR
41
1
482013
BOOT
42
1
482045
BOOT
43
1 486080
SEAL-GEAR HSG.
44
2
488007
SHIM
45
1
490037
SNAP RING
46
6
494110
SPRING-BRAKE
47
4
494112
SPRING
48
1
504021
SWITCH
49
1
509009
TUBE ASSEMBLY
50
1 516013
VALVE-MOTOR CONTROL
51
1
518047
THRUST WASHER
52
1
518052
THRUST WASHER
53
1
416059
SETSCREW-3/8-16NC X ½ HX SOC HD CUP
