PARTS LIST RPH 12,000T WITH MANUAL CLUTCH SHIFTER
ITEM QTY. PART NO. DESCRIPTION
1
1 93758
DRUM ASS'Y.
2
1 276052
SHIFTER ASS'Y.-MANUAL
3
1
306042
PISTON-BRAKE
4
1 338300
END BEARING-MOTOR
5
1 338301
END BEARING-GEAR HOUSING
6
1
338302
HOUSING-BRAKE
7
4
346045
PIN-BRAKE
8
1 357504
SHAFT-INPUT/SUN GEAR
9
2 395172
TIE PLATE
10
1 402120
BEARING-GEAR HSG.
11
1 402121
BEARING-MTR. END BEARING
12
1 412084
BUSHING-DRUM (MTR. END)
13
1 412085
BUSHING-DRUM (G.HSG. END)
14
6 414303
CAPSCREW-3/8-16NC X 2-1/2 LG. HX.HD., GR. 5 PLTD.
15
2
414948
CAPSCREW 1/2-13NC X 1-1/4 LG. SOC.HD.
16
8
414581
CAPSCREW 1/2-13NC X 3/4 LG. HX.HD. GR.5 PLTD.
17
2
414854
CAPSCREW 1/4-20NC X 1/2 LG. RD.HD. SLOT PLTD.
18
4 414868
CAPSCREW 5/16-18NC X 1-1/2 LG. SOC. HD. NYLOK
19
1 414926
SETSCREW-3/8-16NC X 1 LG., SOCKET, NYLON
20
1
416016
SETSCREW-1/4-20NC X 1/4 LG., HX. SOC. HD.
21
1
418036
NUT 3/8-16NC HEX. JAM
22
2 418218
LOCKWASHER-1/2 ID MED. SECT.
23
1
431015
COUPLING-MOTOR
24
2
432018
FITTING-7/16 ELBOW
25
NOT USED
26
4
438022
DISC-BRAKE
27
1
442220
GASKET-BRAKE
28
1
442223
GASKET-MOTOR
29
1 444085
GEAR-RING
30
1
456038
FITTING-VENT
31
1
458090
MOTOR-HYDRAULIC
32
1 462046
O-RING (DRUM)
33
1
462056
O-RING
34
1
462057
O-RING
35
1
462058
O-RING
36
1
462059
O-RING BACKUP
37
1
462060
O-RING BACKUP
38
1
472052
PLUG
39
5 474111
PLATE-SEPARATOR
40
1 486080
SEAL-GEAR HSG.
41
1
490037
SNAP RING
42
6
494110
SPRING-BRAKE
43
4
494112
SPRING
44
1
509009
TUBE ASSEMBLY
45
1 516013
VALVE-MOTOR CONTROL
46
1
518037
THRUST WASHER
47
1
518047
THRUST WASHER
48
1
518052
THRUST WASHER
49
1
416059
SETSCREW-3/8-16NC X ½ HX SOC HD CUP
