PARTS LIST RPH-8,000 WITH MANUAL CLUTCH SHIFTER
ITEM QTY. PART NO. DESCRIPTION
1 1 234165 DRUM ASS'Y. "Y"
1 234166 DRUM ASS'Y. "STD."
2 1 276048 SHIFTER ASS'Y.
3 1 306035 SPRING-FLAT, BRK.
*4 1 314017 CAM PLATE-”A” ROTATION
1 314018 CAM PLATE-”B” ROTATION
5 1 334174 GEAR-OUTPUT, SUN
6 1 444084 GEAR-RING
**7 1 338326 END BEARING-MOTOR
**8 1 338327 HOUSING-GEAR, END BEARING
**9 1 338328 HOUSING-BRAKE
*10 1 314019 HUB PLATE
11 1 352021 RETAINER PLATE
12 1 357489 SHAFT-INPUT "Y"
1 357490 SHAFT-INPUT "STD."
13 2 395163 TIE PLATE "Y"
2 395172 TIE PLATE "STD."
*14 3 400007 BALL
15 1 412084 BUSHING-DRUM, MOTOR END
16 1 412085 BUSHING-DRUM, GEAR
17 2 414273 BOLT-3/8-16NC X 1-3/4, HX, GR. 5
18 8 414581 CAPSCREW-1/2-13NC X 3/4 LG. HX. HD., GR. 5, Z/P
19 1 414622 BOLT-1/2-13NC X 2-1/4, HX. HD., GR. 5, ALL-THD.
20 2 414836 CAPSCREW-1/4-20NC X 1/2, HX. SOC. HD.
21 4 414159 CAPSCREW-5/16-18NC X 2-1/2, HX. HD. GR5 Z/P
22 1 414926 SETSCREW-3/8-16NC X 1, SOCKET, NYLON
23 4 414934 CAPSCREW-3/8-16NC X 2-3/4, HX. SOC. HD.
24 2 414952 CAPSCREW-1/2-13NC X 1-1/2, SOC. HD.
25 1 416016 SETSCREW-1/4-20NC X 1/4 HX. SOC. HD.
**26 2 418034 NUT 3/8-16NC HEX.REG.
27 1 418036 NUT 3/8-16NC HEX. JAM
28 1 418061 NUT-1/2-13NC HEX. JAM
29 4 418184 WASHER-3/8 ID X 5/8 OD X 1/16 FLAT ALUM
30 2 418218 LOCKWASHER-1/2 ID MED. SECT.
31 1 431014 COUPLING-HYD. MOTOR
32 2 438018 PLATE-BRAKE
33 1 442212 GASKET-BRK. HSG.
34 1 456008 RELIEF FITTING
35 1 458074 MOTOR-HYD. (FOR MODEL WITH COUNTERBALANCE VALVE)
1 458075 MOTOR-HYD. (FOR MODEL WITHOUT COUNTERBALANCE VALVE)
36 1 462046 O-RING
37 2 462047 QUAD-RING
38 1 462048 O-RING
39 1 468002 REDUCER
40 2 468018 PIPE PLUG
41 1 470033 SPIROL PIN
*42 1 472051 PLUG
43 1 472052 PLUG
44 1 486076 SEAL
45 1 486080 SEAL-GEAR HSG.
46 1 518037 SHIM
47 2 490003 SNAP RING
48 1 494010 SPRING
49 1 516008 VALVE-COUNTERBALANCE ("A" ROTATION)
1 516009 VALVE-COUNTERBALANCE ("B" ROTATION)
50 1 518047 WASHER-THRUST
*51 1 340077 BRAKE SHAFT
52 4 418163 LOCKWASHER - 5/16 MED SECT Z/P
16
* EFFECTIVE SERIAL NUMBER: 2038147
** EFFECTIVE DATE CODE: H07702041
