Ramsey Winch TRIPLE X - Manual

Congratulations
You have purchased the finest winch available in its serv-
ice class. It features a highly efficient 3 stage planetary
gear set which transmits torque from a series wound DC
motor. A safe positive clutch allows free spooling for
quick rope deployment. An automatic load holding brake
is designed to hold the fully rated capacity of the winch.
It was designed and manufactured to provide you with
the utmost in utility. As with any device that combines
power and movement in its use, there are dangers if
improperly used. At the same time, there are easier ways
for getting the job done if certain precautions are taken
first.
Please read this manual carefully. It contains useful ideas
in obtaining the most efficient operation from your
Ramsey Winch and safety procedures you need to know
before beginning use. When you follow our guidelines for
operation, your Ramsey Winch will give you many years
of satisfying service. Thank you for choosing Ramsey.
You will be glad you have one working for you.
Ramsey Winch Company
Owner’s Manual
Front Mount Electric Winch
Triple X
with synthetic rope
12 volt
Contents
Performance Specifications . . . . . . . . . . . .Front Cover
Safety Precautions . . . . . . . . . . . . . . . . . . . . . . . . . .2
Tips for Safe Operation . . . . . . . . . . . . . . . . . . . . . . .2
Techniques of Operation . . . . . . . . . . . . . . . . . . . . . .3
Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-5
Electrical Connections and Operation . . . . . . . . . . . . .5
Mounting Information . . . . . . . . . . . . . . . . . . . . . . . .6
Operating Instructions . . . . . . . . . . . . . . . . . . . . . . . .8
Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8
Troubleshooting Guide . . . . . . . . . . . . . . . . . . . . . . . .9
Replacement Rope Installation . . . . . . . . . . . . . . . . .10
Rope Inspection . . . . . . . . . . . . . . . . . . . . . . . . . . .11
Winch Parts List . . . . . . . . . . . . . . . . . . . . . . . .12-13
Warranty . . . . . . . . . . . . . . . . . . . . . . . . . .Back Cover
Please note: Ramsey Triple X winches are designed for front mount
vehicle use. The winches are not designed for and should not be
used in industrial applications (car haulers/carriers, wreckers, hoist-
ing, etc.), and Ramsey does not warrant them to be suitable for
such use. Ramsey makes a separate, complete line of winches for
industrial/commercial use. Please contact the factory for further
information.
CAUTION: Read and understand this manual before installation and operation of winch. See Safety Precautions!
Layer of Rope 1 2 3 4
(lbs) 6,000 4,700 3,900 3,300
(kg) 2,720 2,130 1,760 1,490
(ft)* 5 15 25 35
(m)* 1 4 7 10
(lbs) NO 1,000 3,000 5,000 6,000
(kg) LOAD 450 1,350 2,260 2,720
(FPM) 45 23 20 14 12
(MPM) 13.7 7 6.1 4.3 3.7
Amp Draw 12V 100 200 270 350 405
* Depends on rope being uniformly wound onto drum. (3/8" x 35' Synthetic Rope)
Rated Line Pull Per Layer
Cumulative Rope
Capacity Per Layer
Line Pull First Layer
Line Speed First Layer
Fairlead does not mount directly to winch.
Mounting plate for display only.
