1
* DEPENDS ON CABLE BEING UNIFORMLY WOUND ONTO DRUM.
3,480
7,700
2
10
35
97
35.4
10.7
LOAD
NO
LAYER OF CABLE
(5/16"-8mm- dia. cable)
4
15
4,309
9,500
1
3.2
335
2,720
6,000
260 180
3.8
1,810
4,000
16.7
5.1
900
2,000
10.6 12.7
395
9.0
2.7
3,620
8000
18
60
2,940
6,500
24
80
2,580
5,700
3 4
(lbs)
(kgs)
Rated line pull per layer
Cumulative cable
capacity per layer (ft)*
(m)*
Line pull (lbs)
(kgs)
Line speed (fpm)
(mpm)
Amp draw (12v)
9,500
4,309
7.8
2.3
430
first layer
first layer
BAD BOY PLATINUM 9500 COMPETITION WINCH
COMPETITION WINCH
OWNERS MANUAL
Congratulations
You have purchased the finest winch available in its service
class. It features a highly efficient 3 stage planetary gear set
which transmits torque from a series wound D.C. motor. A safe
positive clutch allows free spooling for quick cable deployment.
An automatic load holding brake is designed to hold the full rated
capacity of the winch. It was designed and manufactured to
provide you with the utmost in utility. As with any device that
combines power and movement in its use, there are dangers if
improperly used. At the same time, there are easier and faster
ways for getting the job done if certain precautions are taken
first. Please read this manual carefully. It contains useful ideas
in obtaining the most efficient operation from your Ramsey
Winch and safety procedures you need to know before
beginning use. When you follow our guidlines for operation,
your Ramsey Winch will give you many years of satisfying
service. Thank you for choosing Ramsey. You will be glad you
have one working for you.
Contents
Performance Specifications ........................................ Front Cover
Safety Precautions.......................................................................2
Tips for Safe Operation................................................................2
Te c h n i q u e s o f O p e r a t i o n . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Installation ......................................................... 4
Operating Instructions..................................................................5
Electrical Connections ................................................................ 5
Remote Control Operation ................................... 5
Lubrication/Cable Installation ............................... 5
Trouble Shooting Guide...............................................................6
Winch Parts List........................................................................7-9
Warranty .................................................................... Back Cover
Please Note:
Ramsey Bad Boy Platinum 9500 TM Competition
Winches are designed for front mount vehicle use. The winches
are not designed for and should not be used in industrial
applications (car haulers /carriers, wreckers, hoisting, etc.), and
Ramsey does not warrant them to be suitable for such use.
Ramsey makes a separate, complete line of winches for
industrial/commercial use. Please contact the factory for further
information.
CAUTION: Read and understand this manual before installation and operation of winch. See Safety Precautions
