Ramsey Winch PATRIOT 15000 User Manual
Page 9
7
PATRIOT 15000
Winch Parts List Patriot 15000
Item Qty.
P/N
Description
Item Qty.
P/N
Description
1
1
234192
DRUM ASSEMBLY
30
1
416059
SETSCREW-3/8-16NC X 1/2 LG
2
1
247028
INPUT GEAR CARRIER ASSY
3
1
247035
INTERMEDIATE GEAR CARRIER ASSY
32
2
418049
NUT-7/16-14NC HEX REG Z/P
4
1
251183
ROLLER FAIRLEAD
5
1
251230
CABLE ASSY-90'X7/16" W/HOOK
34
6
418198
LOCKWASHER 7/16
6
1
278178
SOLENOID ASSY 12V
35
4
418204
FLAT WASHER 7/16
1
278187
SOLENOID ASSY 24V
36
1
418458
SPACER-CLUTCH SHAFT
7
1
282001
SWITCH ASSY-12FT LG,STD,
37
1
426042
PLUNGER-CLUTCH,MANUAL
8
1
289141
WIRE ASSY - GROUND
38
1
438033
BRAKE SHELL
9
1
458135
MOTOR - 12V
39
1
442208
GASKET-GEAR HOUSING COVER
1
458136
MOTOR - 24V
40
1
442219
GASKET-RING GEAR
10
1
296600
COUPLING-MOTOR
41
1
444077
GEAR-RING INPUT & INTERMEDIATE
11
1
296601
BRAKE ASSY
42
1
444084
GEAR-RING OUTPUT
12
1
328138
COVER - GEAR HOUSING
43
1
462046
O-RING, 2-1/4 OD X 1/8
13
1
334153
INPUT SUN GEAR
44
1
462064
O-RING, 7/16 OD X 1/16
45
1
470097
SPIROL PIN-1/8 X 3/4
15
1
334184
INTERM SUN GEAR
46
1
470088
PIN-SPRING 1/8 X 5/8
16
1
334193
OUTPUT SUN GEAR
47
1
486080
SEAL- GEAR HOUSING
17
1
336029
CLUTCH LEVER
48
1
489025
SHAFT-SHIFTER CLUTCH
18
1
338334
END BEARING - GEAR
49
1
490037
SNAP RING
19
1
357514
INPUT SHAFT
50
1
494104
SPRING-SHIFTER,CLUTCH
20
2
395419
TIE BAR
51
2
518020
THRUST WASHER-1.39 ID
52
1
518027
THRUST DISC-.035 X .922
22
1
412084
BUSHING-DRUM, MOTOR END
53
1
518066
WASHER-THRUST,.063 THICK
23
1
412085
BUSHING-DRUM, GEAR END
54
1
518060
WASHER-CLUTCH LEVER
24
2
414055
CAPSCREW-1/4-20UNC X 1/2 LG HX HD
55
1
518061
SPACER-INPUT-INTER GEAR
25
4
414038
CAPSCREW-1/4-20UNC X 3/4 LG HX HD
56
1
296602
ON/OFF SWITCH ASSEMBLY (12V)
26
6
414159
CAPSCREW-5/16-18UNC X 2.50 LG HX HD
1
296603
ON/OFF SWITCH ASSEMBLY (24V)
27
4
414462
CAPSCREW-7/16-14NC X 1 LG HX HD Z/P GR5
57
1
525011
HOOK STRAP
28
2
414469
CAPSCREW-7/16-14NC X 1 1/4 LG HX HD Z/P GR5
58
1
338347
END BEARING
29
1
416030
SETSCREW-1/4-20NC X 3/8 HALF DOG POINT
59
1
438042
INSULATOR-BRAKE
