INSTALLATION INSTRUCTIONS
for Doors with Integral Nailing Fin (JII006-ODL)
2
MATeRIALS
• 1 3/4" galvanized roofing nails; nails must penetrate at least 1" into
framing
• Non-compressible or water degradable shims
• 6" wide self-adhesive flashing (9" if required by local code)
• Protecto Wrap Safseal Systems 5500 spray adhesive/primer (or as
recommended by the self-adhesive flashing manufacturer)
• Sealant (polyurethane if painted, 100% silicone if left exposed) and
backer rod
• Plastic drain screen with crisscross or woven pattern (sold in 6" widths
to protect rain gutters) for step-down landings
• Sheet metal flashing or bendable vinyl sheeting for sill pan (4" wide
for 2" x 4" wall)
• 3/8" staples for step-down landings
Note! Follow all material manufacturers’ instructions for proper use
and compatibility.
NeeDeD mATerIALs & TOOLs
TOOLS
• Cutting shears (sill pan)
• Tape measure
• Utility knife
• Level (4 ft. minimum
recommended)
• J-roller
• Caulking gun
• Drill
• Construction stapler
SAFeTy
• Read and fully understand ALL manufacturers’ instructions before
beginning.
• Do not work alone. Two or more people are required. Use safe lifting
techniques.
• Use caution when handling glass. Broken or cracked glass can cause
serious injury.
• Wear protective gear (e.g. safety glasses, gloves, ear protection, etc.).
• Operate hand/power tools safely and follow manufacturer’s operating
instructions.
• Use caution when working at elevated heights.
sAFeTy & hANDLING
MATeRIALS AND PATIO DOOR HANDLING
• Make sure the operating panel is secured prior to installation.
• Heed material manufacturers’ handling and application instructions.
• Protect adhesive surfaces from dirt, moisture, direct sunlight and
folding over onto themselves.
• Handle in vertical position; do not drag on floor.
• Do not put stress on joints, corners or frames.
• Store patio door in dry, well-ventilated area in vertical, leaning
position to allow air circulation; do not stack horizontally.
• Protect from exposure to direct sunlight during storage.
• Install only into vertical walls and when conditions and sheathing are
dry.
• Never use solvent-based sealants on vinyl products.
IF INjURy OCCURS, IMMeDIATeLy Seek MeDICAL ATTeNTION!
ReMOVe PACkAGING
remove shipping materials such as corner covers, shipping blocks or
pads.
INSPeCT PATIO DOOR
• Cosmetic damage
• Product squareness (diagonal measurements must be within 1/4"
difference)
• Correct product (size, color, grid pattern, handing, glazing, energy-
efficiency requirements, etc.)
1
remOVe pACKAGING & INspeCT pATIO DOOr
• Splits, cracks, holes, missing sections or other damage to the nailing
fin longer than 6" and/or within 1/2" of patio door frame
• For side-by-side mulled units, a drip cap that extends the length of the
frame plus 1/8" overhang on each end is required
If any of the above conditions represent a concern, or if you expect
environmental conditions to exceed the patio door's performance
rating, do not install the patio door. Contact your dealer or distributor
for recommendations.
