A-3 INSTALLATION
WIRE FEEDER WELDERS (125, 140, 180 MODELS)
A-3
INCLuDED COMPONENTS
• Wire Feeder
Welder.
• Work Cable & Clamp.
• Magnum 100L Welding Gun.
• 3 .035 Contact Tips (1 installed
on the welding gun).
• 3 .025 Contact Tips.
• Spool of .035 diameter NR-
211MP Innershield Flux-cored
Wire.
• Spool of .025 diameter L-56 MIG
Wire.
• .025-.030 Smooth Drive Roll
• .035 Smooth Drive Roll
• .030 -.045 Knurled
Drive Roll
(Installed on
Machine)
.025
.025 .025 .035 .035
NR-211 MP
WIRE
L-56 MIG
• Magnum 100L Welding Gun.
• 3 .035 Contact Tips (1 installed on
the welding gun).
• Spool of .035 diameter NR-
211MP Innershield Flux-cored
Wire.
• .030 -.045 Knurled Drive Roll
(Installed on
Machine)
• Handshield
• Black Flux-cored Gasless Gun
Nozzle (Installed on Welding Gun)
• 2” Spindle Adapter (For 8” Reel of
wire)
• Learn to Weld (LTW1 Manual)
• DVD
IDENTIFY AND LOCATE
COMPONENTS
for 140 AMP and 180 AMP uNITS
.035 .035
.035 NR-211 MP
FLUX-CORED WIR
E
LTW1
"LEARN TO WELD"
DVD
2" SPINDLE ADAPTER (FOR 8" REEL OF WIRE)
LINCOLN
ELECTRIC
®
•Handshield*
* Handshield not available on Code 11658.
• Black Flux-cored Gasless Gun
Nozzle (Installed on Welding
Gun)
• Brass MIG Gas Gun Nozzle
• 2” Spindle Adapter (For 8” Reel of
wire)
• Regulator
• Gas Hose
• Learn to Weld (LTW1 Manual)
• DVD
• INCLuDED COMPONENTS
• Wire Feeder
Welder.
• Work Cable & Clamp.
LINCOLN
ELECTRIC
®
LTW1
"LEARN TO WELD"
DVD
GAS HOSE
REGULATOR
2" SPINDLE ADAPTER (FOR 8" REEL OF WIRE)
IDENTIFY AND LOCATE
COMPONENTS
for 125 AMP FLuX CORE uNIT
OPERA
T
OR’S MANuAL
