Lincoln Electric IM10047 RED-D-ARC GX300 - Manual (Page 65)

1A Case Side - Right G3510-1 1 X X X`X
1B Thread Forming Screw (Not Shown) S9225-68 3 X X X`X
2A Case Side - Left G3511-1 1 X X X X
2B Thread Forming Screw (Not Shown) S9225-68 3 X X X X
3A Case Back G3865-5 1 X X X X
3B Thread Forming Screw (Not Shown) S9225-68 4 X X X X
3C Fastener Button (Not Shown) T14659-1 2 X X X X
4A Roof G3882-5 1 X • • •
4A Roof G3882-8 1 • X X X
4B Thread Forming Screw S9225-68 16 X X X X
4C Door Bumper (Not Shown) T14882-1 6 X X X X
5A Left Engine Cover L11529-3 1 X X X X
5B Thread Forming Screw (Not Shown) S9225-66 1 X X X X
5C Speed Nut (Not Shown) T11525-5 1 X X X X
6A Right Engine Cover L11528-1 1 X X X X
6B Latch S24694 1 X X X X
6C Hinge S24348 2 X X X X
6D Rivet (Not Shown) T12584-9 6 X X X X
6F Oil Drain Decal S24665 1 X X X X
7 Fuel Trough L12084 1 X X X X
8 Cover Seal S12934-1 1 X X X X
9A Engine Top Cover Welded Assembly G3514-1 1 X • • •
9A Engine Top Cover Welded Assembly G3514-3 1 • X X X
9B Latch S24694 1 X X X X
9C Door Bumper (Not Shown) T14882 2 X X X X
9D Rivet (Not Shown) T12584-6 2 X X X X
9E Rivet (Not Shown) T12584-9 2 X X • •
9E Rivet (Not Shown) T12584-12 2 • • X X
10 Battery Caution Decal S17851 1 X X X X
11 Warning Label M16197 1 X X X X
12 Fuel Warning Decal T13086-108 1 X X X X
13 Wiring Diagram G6852 1 X X X X
16 Engine Decal S26884 1 X X X •
16 Engine Service Decal S29943 1 • • • X
18 Warning Decal S25896 1 X X X X
19 CO Warning Decal M21436 1 X X X X
23 Foam Airbox M22367 1 X X X X
25A Battery Cover M22185-1 1 X X X X
25B Thread Forming Screw S9225-68 3 X X X X
26 Decal (Code Number) (Not Shown) S23760-4 1 X X X X
27A Side Decal (G3399-1-R1) (Part of G3399-1) NSS 1 X X X X
27B Side Decal (G3399-1-R2) (Part of G3399-1) NSS 1 X X X X
27C Side Decal (G3399-1-L1) (Part of G3399-1) (Not Shown) NSS 1 X X X X
27D Side Decal (G3399-1-L2) (Part of G3399-1) (Not Shown) NSS 1 X X X X
28 Fuel Filling Warning Decal (Not Shown) T13086-215 1 X X X X
04-23-2013
RED-D-ARC GX300
Use only the parts marked “x” in the column under the
heading number called for in the model index page. # Indicates a change this printing.
P-642-J.1
ITEM DESCRIPTION PART NO. QTY. 1 2 3 4 5 6 7 8 9
P-642-J.1
NSS - Not Sold Separately
