Lincoln Electric IM10047 RED-D-ARC GX300 - Manual (Page 55)

1A Base G3870-1 1 X X X X
1B Hinge Assembly S24295-2 2 X X X X
1C Rivet (Not Shown) T12584-9 4 X • X •
1C Rivet (Not Shown) T12584-12 4 • X • X
1D Door Bumper (Not Shown) T14882-1 4 X X X X
2A Engine Cross Support L11147-1 1 X X X X
2B Thread Forming Screw S9225-68 6 X X X X
4 Fuel Tank & Assembly, Includes: L12164-1 1 X • • •
4 Fuel Tank & Assembly, Includes: L12164-4 1 • X • •
4 Fuel Tank & Assembly, Includes: L16027 1 • • X •
4 Fuel Tank & Assembly, Includes: L12164-6 1 • • • X
4A Fuel Tank NSS 1 X X X X
4B Fuel Sender M20302 1 X X X X
4C Fuel Pick-Up Tube Assembly S19565-4 1 X X X X
4D Rubber Plug S19563 1 X X X X
4E Fuel Cap S20541 1 X • • •
4E Ratchet Fuel Cap (No longer part of Fuel Tank Asbly) S28521 1 • X X X
4F Remote Vent Valve M22694 1 • X X X
4G Rubber Plug S28522 1 • X X X
4H EPA Compliance Decal (Not Shown) NSS 1 • X X X
5 Rectifier, Choke, Stator Support, Includes: L11135-3 1 X X X X
5A Stator Support Bracket L11010 1 X X X X
5B Choke Assembly M19416 1 X X X X
5C 5/16-18 x 2.50 HHCS CF000187 3 X X X X
5D Lock Washer (Not Shown) E106A-14 3 X X X X
5E Plain Washer (Not Shown) S9262-121 1 X X X X
5F 5/16-18 HN (Not Shown) CF000029 3 X X X X
5G 3 Phase Bridge Rectifier L11132-3 1 X X X X
5H Lock Washer (Not Shown) E106A-14 2 X X X X
5J Rubber Mounting S24344 2 X X X X
5K 3/8-16 x 2.50 HHB CF000196 2 X X X X
5L Plain Washer S9262-113 2 X X X X
5M 3/8-16 HN CF000067 2 X X X X
5N Plain Washer S9262-47 4 X X X X
5P Thread Forming Screw S9225-68 6 X X X X
7 12 Volt Storage Battery (M9399-14) NSS 1 X X X X
8A Battery Bracket S27320-1 1 X X X X
8B J-Bolt T8818-14 2 X X X X
8C Lock Washer E106A-2 2 X X X X
8D Plain Washer S9262-98 2 X X X X
8E 1/4-20 HN CF000017 2 X X X X
9A Battery Cable (Neg.) (Not Shown) S8070-20 1 X X X X
9B Battery Cable (Pos.) (Not Shown) S8070-11 1 X X X X
9C Battery Terminal Cover (Not Shown) S20191-1 1 X X X X
9D Plastic Cap (Not Shown) T14654 1 X X X X
10 Fuel Tank Brace G4003-2 1 X X X X
17A Electric Fuel Pump M20393 1 X X X X
17B Fuel Pump Bracket S25778 1 X X X X
17C Thread Forming Screw S9225-68 4 X X X X
17D Plain Washer S9262-98 2 X X X X
17E Flex Tube (Supplied w/Engine) NSS 1 X X X X
Jan-14
RED-D-ARC GX300
Use only the parts marked “x” in the column under the
heading number called for in the model index page. # Indicates a change this printing.
P-642-E.1
ITEM DESCRIPTION PART NO. QTY. 1 2 3 4 5 6 7 8 9
P-642-E.1
NSS - Not Sold Separately
