1A Rotor & Shaft Assembly L11086-2 1 X
1B Centering Washer S20110-3 1 X
1C Special Hex Head Bolt T14843-6 1 X
1D Tolerance Ring S18044-9 1 X
1E Blower L9033 1 X
1F Plain Washer S9262-149 1 X
1G Bearing M9300-85 1 X
2A Firewall G3849-1 1 X
2B Bushing T12380-1 1 X
2C Bushing T12380-6 1 X
5A Brush & Brush Holder Assembly, Includes: M16158 1 X
Brush Holder Cartridge G2114 1 X
Brush Assembly, Includes: S19480 2 X
Brush Clip S19475 2 X
Compression Spring T11862-44 2 X
Brush S19474 2 X
Brush Assembly Retainer M16157 1 X
5B Brush Holder Bracket M18336 1 X
5C Self Tapping Screw (Not Shown) S8025-91 2 X
5D 1/4-20 x 1.00 HHCS (Not Shown) CF000015 2 X
5E Lock Washer (Not Shown) E106A-2 2 X
5F 1/4-10 HN (Not Shown) CF000017 2 X
7A Stator Frame Assembly G3541-7 1 X
7B 3/8-16 x 1.25 HHCS (Not Shown) T8833-10 2 X
7C Lock Washer (Not Shown) E106A-4 2 X
8A Solenoid Assembly S20752 1 X
8B Self Tapping Screw S8025-91 3 X
9A Pull Wire S20848 1 X
9B Bracket (Not Shown) S21177 1 X
9C Bushing, Linkage Retaining (Not Shown) S21015 2 X
10 Spring T6778 1 X
11 Plunger S21020 1 X
12 Plain Washer S9262-98 1 X
13 1/4-20 HJN T9187-1 1 X
15 Flex Tube (Oil Drain) (On Slots of Firewall) (Not Shown) T10642-242 1 X
04-23-2013
RED-D-ARC GX300
Use only the parts marked “x” in the column under the
heading number called for in the model index page. # Indicates a change this printing.
P-642-H.1
ITEM DESCRIPTION PART NO. QTY. 1 2 3 4 5 6 7 8 9
P-642-H.1
