A-2
INSTALLATION
POWER WAVE
®
R350
A-2
PHYSICAL DIMENSIONS
TEMPERATURE RANGES
HEIGHT
20.40 in ( 518 mm)
MODEL
K3022-1
WIDTH
14.00in ( 356 mm)
DEPTH
24.80in ( 630mm)
WEIGHT
85 lbs (39 kg)*
OPERATING TEMPERATURE RANGE
Environmentally Hardened: -4°F to 104°F (-20C to 40C)
STORAGE TEMPERATURE RANGE
Environmentally Hardened: -40°F to 185°F (-40C to 85C)
PROCESS
GMAW
GMAW-Pulse
FCAW
GTAW-DC
OUTPUT RANGE (AMPERES)
40-350A
5-350A
OCV (U
o
)
Mean Peak
40-70V
100V
24V
WELDING PROCESS
IP23 155º(F) Insulation Class
*
Weight does not include input cord.
Thermal tests have been performed at ambient tem-
perature. The duty cycle (duty factor) at 40°C has
been determined by simulation.
