Page 12
A-5
INSTALLATION
POWER WAVE
®
R350
A-5
CONNECTION DIAGRAM
GMAW (MIG) WELDING
An arclink compatible wire feeder is recommended for
Mig welding. Refer to Figure A.2 for the connection
details.
MIG PROCESS
REGULATOR
FLOWMETER
GAS HOSE
WORK PIECE
WORK CLAMP
TO POSITIVE
(+) STUD
TO NEGATIVE (-) STUD
PF10-M
WIRE FEEDER
ARCLINK CABLE
K1543-[XX]
FIGURE A.2
